Kvadrat Medium Ghibson Kontraventil GA

Ghibson - Wafer check valve GA 015 is available in DN 15 to DN 100 - 1/2”to 4”, Pmax 52 bar. Moreover, it is small in size, low in weight and an opening pressure from 20 to 500 mbar. Available with house, disc, seat plate and spring in stainless steel and other materials on request.

For sales or commercial inquiries please contact us at marine@insatech.com.

Contact us now

To flanges

  • DN 15 to DN 80 PN 6 to PN 40, ANSI 150 to ANSI 300
  • DN 100 PN 10 to PN 40, ANSI 150 to ANSI 300

Properties

  • Small in size and low in weight
  • Opening pressure from 20 to 500 mbar
  • Can be installed in all positions

169 Ghibson Wafer Kontraventil GA 015
Insatech Medarbejdere Website MSR
For technical questions

Martin Søvind Jensen


Tel: +45 2761 4502

Email: Martin.Sovind@insatech.com

Write to Martin

Insatech Medarbejdere Website ASMI
For commercial inquiries

Astrid Mihut


Tel.: +45 5537 2095

Email: Marine@insatech.com



Contact us now

Technical Specifications
To flanges
  • DN 15 to DN 80 PN 6 to PN 40, ANSI 150 to ANSI 300
  • DN 100 PN 10 to PN 40, ANSI 150 to ANSI 300

Ghibson - special spring table

Opening pressure

20 - 500 mbar with special springs (± 10%)

Materials
  • House: Stainless steel
  • Disc: Stainless steel (standard). Possibility of softening with either NBR, EPDM or FKM
  • Seat plate: Stainless steel. Possibility of softening with PTFE
  • Spring: Stainless steel (standard) - Hastelloy (on request)
Certificate

Possibility of 3.1 material certificate

Product specifications and manuals

  • Ghibson - Brochure, Wafer check valve GA 015
    English | pdf
  • Ghibson - Certificate, Check valve GA, GB, GN, GT, PED
    English | pdf
