Temperature Calibrator TC15 IKM

Temperature Calibrator TC15

The Temperature Calibrator TC15 from IKM Instrutek meets all Dry Block Calibrator classification requirements. The calibrator comes with a traceable calibration certificate, and in a solid carrying case. Low weight means that the calibrator is suitable for calibration on the spot.

Key advantages:

Calibration on the spot
User friendly
Removable lining
Traceable calibration certificate.

We deliver directly and globally to end-users, agents, and resellers.
Contact us at quotes@insatech.com.

Get a quote

Effortless Operation: Easy-to-Use

The dry block principle eliminates the need for oils or liquids. With interchangeable dry block inserts of various diameters, optimal thermal contact with the sensor under test is ensured.

Calibration is a breeze – just position the sensor in the calibrator, select the desired temperature, wait for stabilization, and then simply read the accurate temperature displayed by the calibrator.

Easily recalibrate your sensor or system based on this precise reading.

Advantages for you:

The Temperature Calibrator, TC15, from IKM has several benefits including, but not excluded to:

3 years calibration interval
Touchscreen interface
Temperature Range: -40°C to 150°C
Accuracy: ±0,3°C
Stability: ±0,05°C
Liquid-free, secure dry calibration
110 mm well depth.

Need our help? Contact us now.

Precise Calibrations for Demanding Environments

IKM Instrutek's calibrators are meticulously engineered to maintain exceptional accuracy and stability even in the harshest conditions.

These portable calibrators are trusted by offshore rig operators and leading ship owners across the globe.

Exactly what you need? Contact us here

Certified Accuracy and Compliance

Every calibrator supplied by IKM Instrutek undergoes rigorous calibration against precision equipment, all traceable to national standards.

Rest assured, each unit comes with a calibration certificate, guaranteeing its precision and compliance.

The calibrators are designed to meet the stringent requirements of quality assurance programs and classification societies. Plus, their lightweight and compact design make them the ideal choice for on-site calibration.

Thus, you get precision, wherever you are!

Calibration FAQs

What Is a Calibration?

A calibration is a comparison between a known measurement (a more accurate standard) and the measurement using your instrument.

A general rule of thumb is that the standard should be ten times more accurate than your own instrument. However, accuracy ratio of 3:1 may also be used in some cases. The objective of a calibration is simply to determine the accuracy of your measuring device.

When Should You Calibrate?

Your instrument should be calibrated:

According to recommendation of the manufacturer.
According to class demands, IOPP certification etc.
After any electrical or mechanical shock.
Periodically (annually, quarterly, monthly).

Hidden costs and risks associated with un-calibrated devices could be much higher than the cost of the calibration.

How is the calibration data documented?

The multifunction calibrator logs calibration results electronically. Data can be downloaded via USB, ensuring traceability and easy reporting for audits or compliance documentation.

For technical questions

Martin Søvind Jensen

Tel: +45 2761 4502

Email: Martin.Sovind@insatech.com

Write to Martin

For commercial inquiries

Astrid Mihut

Tel.: +45 5537 2095

Email: Marine@insatech.com

We Deliver Directly to End Customers, Resellers, and Agents – Globally

At Insatech, we are proud to offer our high-quality products to all customers worldwide. Whether you’re an end customer, a reseller, or an agent, you can purchase directly from us.

By choosing us, you gain direct access to all our products, eliminating the need for intermediaries. Our global distribution possibilities ensure fast and reliable delivery to your doorstep, wherever you are.

We strive to make it easy for you as an end consumer to find the products you are looking for while supporting agents and resellers looking to grow their business. Whether you’re buying for your use or resale, we’re here to meet your needs.

Discover how simple it is to work directly with a trusted global distributor – shop with confidence at Insatech today!

Technical Specifications
Temperature range	-40°C* to 150°C
Resolution (display)	0,1°C
Accuracy 1 year	±0,3°C
Accuracy 3 years	±1,2°C
Stability	±0,05°C
Axial gradients (Euramet/cg-13/v.2.0)	±0,4°C
Heating time to max	50 min.
Cooling time	20 min. (150°C to -40°C) Relative to ambient.
Thermostat test	Yes
USB	Yes
Well depth	110 mm
Well diameter	19 mm
Power supply	120-230 VAC, 50/60 Hz
Power consumption	180 Watt
Operating temp.	0 to 40°C
Dimension	122 x 345 x 240 mm
Weight	Approx. 5,5 kg.

Specifications & Manuals

Datasheet - TC15 - IKM Instrutek
English | pdf

Download
Manual - TC15 - IKM Instrutek
English | pdf

Download
Certification - DNV GL - TC15 - IKM Instrutek
English | pdf

Download
