LMP 331
The LMP 331 from BD Sensors is a screw-in transmitter, which is designed to measure level continuously. Moreover, the modular construction of the transmitter gives you a high degree of flexibility, when adapting it to your application.
This is a transmitter that also gives you exceptional performance and vigorous construction.
For sales or commercial inquiries please contact us at marine@insatech.com.
The screw-in transmitter LMP 331 is precise and has the following features that benefits you:
The LMP 331 from BD Sensors is applicable in various settings:
The probe can also be used for various media including fuels, oils, and water.
If you have a specific need the screw-in transmitter LMP 331 is available with optional features like:
As mentioned above, the LMP 331 has the optional features e.g., an intrinsically safe version or a functionally safe version (SIL 2), which both increase your advantages when launching and realizing projects for systems.
| Model/ Type | |||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Pressure | 430: in bar 431: in H2O |
||||||||||||||||||
| Input | [mH2O] [bar] |
||||||||||||||||||
| Pressure port | 1: stainless steel 1.4404 (316L) 9: customer |
||||||||||||||||||
| Diaphragm | 1: stainless steel 1.4435 (316L) 9: customer |
||||||||||||||||||
| Output | 1: 4 … 20 mA / 2-wire 2: 0 … 20 mA / 3-wire 3: 0 … 10 V / 3-wire E: intrinsic safety 4 … 20 mA / 2 wire 1S: SIL2 4 … 20 mA / 2-wire ES: SIL2 with intrinsic safety 4 … 20 mA / 2-wire 9: customer |
||||||||||||||||||
| Seals | 1: FKM 3: EPDM 9: customer |
||||||||||||||||||
| Electrical connection | 100: male and female plug ISO 4400 200: male plug Binder series 723 (5-pin) TA0: cable outlet with PVC cable (IP67) (Note 1) TR0: cable outlet, cable with ventilation tube (IP68) (Note 2) M10: male plug M12x1 (4-pin) / metal for analog output 850: compact field housing stainless steel 1.4301 (304) 999: customer |
||||||||||||||||||
| Accuracy | standard for pN ≥ 0.4 bar 3: 0.35 % FSO standard for pN < 0.4 bar 5: 0.50 % FSO option 1 for pN ≥ 0.4 bar 2: 0.25 % FSO option 2 1: 0.10 % FSO (Note 3) 9: customer |
||||||||||||||||||
| Special version | 000: standard 999: customer |
||||||||||||||||||
| Notes | 1: standard: 2 m PVC cable without ventilation tube (permissible temperature: -5 … 70 °C), others on request 2: code TR0 = PVC cable, cable with ventilation tube available in different types and lengths 3: not in combination with SIL. |
||||||||||||||||||
If you are looking for some specific material, please write to us. Then we will try to find it for you, and send it as soon as possible.
