Wafer Check Valve GN011
Ghibson - Wafer check valve GN 011, is available in DN 15 to DN 100 - 1/2 ”to 4”, Pmax 52 bar. Moreover, it is small in size, low in weight, and can be installed in all positions. Disc, spring, and seat in stainless steel and house in galvanized steel.
Features:
For sales or commercial inquiries please contact us at marine@insatech.com.
The GN011 is available with flanges:
The body is made of galvanized steel, which is suitable for environments with low to moderate corrosion risk. It is often a more cost-effective solution than stainless steel or specialty alloys like Hastelloy. This material can be a suitable choice for less aggressive marine applications.
The GN011 offers flexibility in terms of installation positions, providing:
The valve can serve as a vacuum breaker, pressure relief, and bottom valve. Its significance in the maritime sector lies in:
Critical for maritime systems, the valve maintains optimal pressure, safeguarding pipelines and components. It prevents excessive pressure that can lead to leaks or explosions, crucial on space-constrained ships with elevated accident risks.
Rapid system changes can cause vacuum formation in pipelines, damaging components and hindering functions like cooling or sanitation. The valve halts vacuum formation, ensuring stable operation.
In maritime operations, efficient tank or system drainage is paramount. The valve's bottom functionality facilitates controlled drainage of tanks, ensuring ship stability and safety.
A multi-purpose valve minimizes maintenance needs, saving time and resources for onboard crews.
Limited space on ships calls for efficient design. The valve's versatility reduces the need for multiple components, freeing up space and simplifying piping systems.
This multifunctional valve enhances system management and operation, yielding better performance, reduced waste, and cost savings.
| Technical Specifications | |||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| For flanges | DN 15 to DN 100 - PN 10 to PN 40, ANSI 150 and ANSI 300
|
||||||||||||||||||
| Opening pressure | 20 - 500 mbar with special springs (± 10%) |
||||||||||||||||||
| Materials |
|
||||||||||||||||||
| Certificate | Possibility of 3.1 material certificate |
||||||||||||||||||
If you are looking for some specific material, please write to us. Then we will try to find it for you, and send it as soon as possible.
