Radar specially developed for water applications

Compared to the previous ultrasound technology, radar offers significant advantages in many applications in water treatment and wastewater systems.

Design and price are optimized for this industry.

Touchless radar level measurement with encapsulated antenna system.

Used for continuous level measurement of fluids in containers and tanks.

Measuring range up to 15 m. IP68

Instrument versions:

Due to the simple instrument structure, only a few variants of the VEGAPULS WL 61. are available with an antenna size of 80 mm. The electronics are available in 4 ... 20 mA / HART, Profibus PA and Foundation Fieldbus. Standard length connecting cable is 6 m, other cable lengths longer than 6 m can be selected.

Accurate level measurement.

  • Level measurement of water, wastewater and aggressive liquids (DK value> 2).
  • Accuracy ± 2 mm.
  • Measurement is unaffected by process pressure, temperature and gases.

Easy to commission and service.

  • Can be mounted and adjusted without having to fill or empty the container.
  • Easy setting with display, PC software or HART® terminal.
