A targeted response to the challenges in the water and wastewater sector

VEGAPULS WL S 61 has been developed for the water and wastewater sector. Fog, rain, temperature fluctuations and various. weather conditions have no effect on the radar level measurement.

It has a degree of protection IP68, which allows the radar sensor to withstand being submerged in water, in addition it can be used in connection with venturi or assault measurement for flow measurement.

VEGAPULS WL S 61 is made with Bluetooth, which means that you can set the radar sensor wirelessly via smartphone, PC or tablet.

  • Measuring span: Up to 8 m
  • Cable: 12 m PUR cable
  • Output signal: 4… 20 mA
  • Process connection: G1½
  • Bluetooth adjustment
  • Degree of protection: IP66 / 68 (2 bar)

For setting via smartphone or tablet: Download VEGA's own app called VEGA TOOLS. Find the app via the link here.

For setting via PC: Get VEGA's USB Bluetooth adapter (as a purchase for the product) together with the PACTware setup software (downloadable on VEGA's website) giving them full access to all parameters on the erase sensor.
