Yokogawa differential pressure transmitter

Standard differential pressure transmitter with digital silicon resonance sensor, fitted with flange attachment.

In applications where the container is pressurized, it is possible to mount impulse tubes to compensate for static pressure.

Used for level measurement where membrane attachment is required.

This can be eg be because the product being measured is aggressive, unclean or adherent.

For assignments with inserts, Insatech also has the supplier Badotherm, which allows for a larger selection of inserts.

Measuring ranges from 10 mbar to 5 bar distributed over 2 different measuring cells.

Accuracy ± 0.075% of span.

Output signal two-conductor 4 - 20 mA DC with digital communication.

BRAIN or HART protocol overlaid in 4 - 20 mA signal.

Opportunity for the Fieldbus Foundation or Profibus PA.

Standard SIL 2 approved.
